Tablespace usage monitoring script

      1 Comment on Tablespace usage monitoring script
set feedback off
set pagesize 70;
set linesize 2000
set head on
COLUMN Tablespace format a25 heading 'Tablespace Name'
COLUMN autoextensible format a11 heading 'AutoExtend'
COLUMN files_in_tablespace format 999 heading 'Files'
COLUMN total_tablespace_space format 99999999 heading 'TotalSpace'
COLUMN total_used_space format 99999999 heading 'UsedSpace'
COLUMN total_tablespace_free_space format 99999999 heading 'FreeSpace'
COLUMN total_used_pct format 9999 heading '%Used'
COLUMN total_free_pct format 9999 heading '%Free'
COLUMN max_size_of_tablespace format 99999999 heading 'ExtendUpto'
COLUM total_auto_used_pct format 999.99 heading 'Max%Used'
COLUMN total_auto_free_pct format 999.99 heading 'Max%Free'
WITH tbs_auto AS
 (SELECT DISTINCT tablespace_name, autoextensible
 FROM dba_data_files
 WHERE autoextensible = 'YES'),
 files AS
 (SELECT tablespace_name, COUNT (*) tbs_files,
 SUM (BYTES/1024/1024) total_tbs_bytes
 FROM dba_data_files
 GROUP BY tablespace_name),
 fragments AS
 (SELECT tablespace_name, COUNT (*) tbs_fragments,
 SUM (BYTES)/1024/1024 total_tbs_free_bytes,
 MAX (BYTES)/1024/1024 max_free_chunk_bytes
 FROM dba_free_space
 GROUP BY tablespace_name),
 AUTOEXTEND AS
 (SELECT tablespace_name, SUM (size_to_grow) total_growth_tbs
 FROM (SELECT tablespace_name, SUM (maxbytes)/1024/1024 size_to_grow
 FROM dba_data_files
 WHERE autoextensible = 'YES'
 GROUP BY tablespace_name
 UNION
 SELECT tablespace_name, SUM (BYTES)/1024/1024 size_to_grow
 FROM dba_data_files
 WHERE autoextensible = 'NO'
 GROUP BY tablespace_name)
 GROUP BY tablespace_name)
SELECT c.instance_name,a.tablespace_name Tablespace,
 CASE tbs_auto.autoextensible
 WHEN 'YES'
 THEN 'YES'
 ELSE 'NO'
 END AS autoextensible,
 files.tbs_files files_in_tablespace,
 files.total_tbs_bytes total_tablespace_space,
 (files.total_tbs_bytes - fragments.total_tbs_free_bytes
 ) total_used_space,
 fragments.total_tbs_free_bytes total_tablespace_free_space,
 round(( ( (files.total_tbs_bytes - fragments.total_tbs_free_bytes)
 / files.total_tbs_bytes
 )
 * 100
 )) total_used_pct,
 round(((fragments.total_tbs_free_bytes / files.total_tbs_bytes) * 100
 )) total_free_pct
 FROM dba_tablespaces a,v$instance c , files, fragments, AUTOEXTEND, tbs_auto
WHERE a.tablespace_name = files.tablespace_name
 AND a.tablespace_name = fragments.tablespace_name
 AND a.tablespace_name = AUTOEXTEND.tablespace_name
 AND a.tablespace_name = tbs_auto.tablespace_name(+)
order by total_free_pct;
